The 2026 Mazda CX-5 can tow up to 1,500 pounds when properly equipped, a single rating that holds steady across every trim in the redesigned lineup, from the base 2.5 S to the loaded Premium Plus.
At Team Mazda in Caldwell, we get a lot of questions from shoppers who want to tow a small trailer, a couple of jet skis, or a pop-up camper without stepping up to a larger, thirstier SUV. The short answer for the redesigned 2026 CX-5 is 1,500 pounds, and that number doesn’t change no matter which of the five trims you choose, since every 2026 CX-5 shares the same 187-horsepower SKYACTIV-G engine and standard i-Activ all-wheel drive. If you want the full picture on this year’s redesign first, our 2026 Mazda CX-5 overview is a good starting point.
Key Highlight
Every 2026 Mazda CX-5 trim is rated to tow up to 1,500 pounds when properly equipped, with a curb weight of 3,856 pounds and a GVWR of 4,914 pounds across the entire lineup.
This guide breaks down exactly what that 1,500-pound rating means in real-world terms: what you can and can’t safely tow, how to add a genuine Mazda hitch, and how the CX-5 stacks up against other compact SUVs like the Honda CR-V and Toyota RAV4. We’ll also explain why this year’s rating is lower than what some 2025 CX-5 trims offered, which you can see in detail in our 2026 vs. 2025 CX-5 comparison.
Key Takeaways
- The 2026 Mazda CX-5 has a maximum towing capacity of 1,500 pounds when properly equipped, the same rating across all five trims
- Every trim shares the same 187-horsepower 2.5-liter SKYACTIV-G engine and standard i-Activ all-wheel drive, which is why the tow rating doesn’t change by trim
- Towing capacity dropped from up to 2,000 pounds on certain 2025 CX-5 trims, since Mazda simplified the 2026 engine lineup to a single naturally aspirated option
- A genuine Mazda trailer hitch receiver and wiring harness are available as accessories and are not standard equipment on any trim
- 1,500 pounds is enough for small utility trailers, jet ski trailers, and bike or kayak trailers, but not full-size travel trailers or heavily loaded enclosed trailers
- Curb weight is 3,856 pounds with a GVWR of 4,914 pounds, consistent across the entire 2026 CX-5 lineup
2026 Mazda CX-5 Towing Capacity Explained
Mazda rates the 2026 CX-5 at a maximum towing capacity of 1,500 pounds when properly equipped, and that figure applies uniformly across the 2.5 S, 2.5 S Select, 2.5 S Preferred, 2.5 S Premium, and 2.5 S Premium Plus. Unlike some competitors that reserve higher tow ratings for upper trims or optional powertrains, every 2026 CX-5 leaves the factory with the same 187-horsepower, 186 lb-ft SKYACTIV-G 2.5-liter engine, a six-speed automatic transmission, and standard i-Activ AWD, so the towing math stays identical no matter which trim you drive off our lot in Caldwell.
That 1,500-pound figure is actually a step down from what some 2025 CX-5 trims offered. Last year’s turbocharged models were rated for up to 2,000 pounds, but Mazda dropped the turbo option entirely for the 2026 redesign in favor of a single, refined naturally aspirated engine. The tradeoff is a quieter, more efficient CX-5 with a slightly lower ceiling for towing, which is worth knowing if hauling a trailer regularly is a priority for you.
1,500-LB Tow Rating
Every 2026 CX-5 trim is rated to tow up to 1,500 pounds when properly equipped with a genuine hitch and wiring harness.
187-HP Engine
The same naturally aspirated 2.5-liter engine and 6-speed automatic power every 2026 CX-5 trim, so towing capability never varies by trim level.
3,856-LB Curb Weight
With a GVWR of 4,914 pounds, the CX-5’s weight figures stay consistent across the lineup, which keeps the tow rating predictable.
If towing is a regular part of your routine rather than an occasional need, it’s worth having an honest conversation with our team about whether the CX-5’s 1,500-pound rating fits your plans. Call us at 208-455-0322 to talk through your specific towing needs.
Adding a Tow Hitch to Your 2026 CX-5
Towing capability isn’t built into the CX-5 out of the box; you’ll need a hitch receiver and a wiring harness to legally and safely tow a trailer. Mazda offers a genuine hitch receiver kit designed specifically for the redesigned CX-5’s frame, and it’s available as a genuine Mazda accessory rather than a factory-installed option on any trim. The kit is a three-piece unit with brackets that bolt directly to the frame, so it’s built to the same fit and finish standards as the rest of the vehicle.
You’ll also need a wiring harness to power your trailer’s brake lights and turn signals, which is typically purchased alongside the hitch. If you’re not comfortable with a driveway installation, our service team can install both the hitch and harness for you. You can request pricing and check part availability for your specific CX-5 trim through our parts ordering page, then schedule installation once the parts are in.
| Hitch Kit Component | Purpose | Typically Sold |
|---|---|---|
| Hitch Receiver | Frame-mounted mounting point for the trailer ball or accessory | As a genuine Mazda accessory |
| Wiring Harness | Powers trailer brake lights and turn signals | Sold alongside the hitch receiver |
| Ball Mount & Ball | Connects the trailer coupler to the receiver | Sold separately based on trailer type |
What’s Included in the Genuine Mazda Hitch Kit?
The genuine hitch kit includes the frame-mounted receiver and the hardware needed to secure it, engineered specifically for the 2026 CX-5’s chassis rather than a universal fit. It does not include the ball mount, hitch ball, or wiring harness, which are sold separately depending on your trailer’s coupler size and lighting needs. Our parts team can help make sure you order the correct combination the first time.
Should I Have the Hitch Installed at the Dealership?
Many owners choose dealership installation for peace of mind, since it involves working around the rear bumper cover and support bracket. A professional install also ensures the wiring harness is integrated correctly with the CX-5’s rear sensors, since plugging in trailer lights automatically adjusts how the rear parking sensors behave. If you’re mechanically inclined, DIY installation is possible, but we’re happy to handle it for you at our Caldwell service center.
What Can the 2026 CX-5 Actually Tow?
A 1,500-pound rating sounds abstract until you compare it to real trailers and gear. In practical terms, the 2026 CX-5 comfortably handles small open utility trailers with light cargo, single or double jet ski trailers, bike and kayak trailers, and compact ATV trailers. Many small teardrop-style campers also fall within this range, though it’s important to check the specific trailer’s dry weight plus any gear you plan to pack before you leave the driveway.
What the CX-5 is not built for is anything close to a full-size travel trailer, most of which weigh well over 4,000 pounds empty, or a loaded enclosed cargo trailer. Boats over roughly 1,000 to 1,200 pounds including the trailer itself are also generally too heavy. If your plans regularly involve hauling something in that heavier range, it’s worth discussing more capable options in our lineup, including how the CX-5 compares to the CX-50.
| Trailer or Load Type | Typical Weight | Fits Within 1,500-LB Limit? |
|---|---|---|
| Small Open Utility Trailer | 500–900 lbs loaded | Yes |
| Single or Double Jet Ski Trailer | 900–1,400 lbs loaded | Yes, in most cases |
| Teardrop or Small Pop-Up Camper | 1,200–1,800 lbs dry | Some models only |
| Full-Size Travel Trailer | 4,000+ lbs dry | No |
How Much Tongue Weight Can the CX-5 Handle?
As a general towing rule, tongue weight should run about 10 to 15 percent of your trailer’s total loaded weight. At the CX-5’s 1,500-pound maximum, that works out to roughly 150 to 225 pounds of tongue weight, which falls comfortably within what the genuine hitch receiver is rated to handle. Loading your trailer so more weight sits toward the front, near the tongue, helps keep the CX-5 stable at highway speeds.
Is the CX-5 a Good Choice for Occasional Towing?
For drivers who tow a few times a year, like hauling a small trailer to the lake or moving a couple of kayaks, the CX-5’s 1,500-pound rating is plenty. It’s drivers who tow heavier loads regularly, such as a full-size camper or a boat, who should look at a larger SUV or truck instead. Our team at Team Mazda can walk through your specific towing plans and help you decide honestly whether the CX-5 fits.
2026 Mazda CX-5 Towing Capacity vs. the Competition
Towing capacity is one area where the compact SUV segment varies quite a bit. The 2026 CX-5’s 1,500-pound rating ties it with the Honda CR-V, while the Hyundai Tucson offers a bit more room at 2,000 pounds, and the Toyota RAV4 leads the group by a wide margin at up to 3,500 pounds on properly equipped trims. Here’s how the numbers stack up.
| Vehicle | Max Towing Capacity | Starting MSRP |
|---|---|---|
| 2026 Mazda CX-5 | 1,500 lbs | $29,990 |
| Honda CR-V | 1,500 lbs | $32,370 |
| Hyundai Tucson | 2,000 lbs | $31,050 |
| Toyota RAV4 | Up to 3,500 lbs | $33,495 |
Why Does the RAV4 Tow More Than the CX-5?
The RAV4’s higher tow ratings come largely from its hybrid and plug-in hybrid powertrains, which pair a gasoline engine with electric motors to generate more low-end torque, plus specific trims engineered and tested for higher trailer weights. The CX-5 prioritizes a lighter, more efficient naturally aspirated engine and refined driving dynamics over maximum towing capability, which is a deliberate tradeoff in how Mazda positions the vehicle.
Should Towing Capacity Be a Dealbreaker When Choosing the CX-5?
For most Caldwell-area drivers, no. The CX-5’s 1,500-pound rating comfortably covers small trailers, jet skis, and light gear, which is what the majority of compact SUV owners actually tow. If you know you’ll regularly need to pull something heavier, that’s worth factoring into your decision, but for occasional or light-duty towing, the CX-5 remains a strong, efficient choice.
